Natural Nylon 6

from £3.00

Offer: £5 standard delivery. Checkout today!
Natural Nylon 6 image

Step 1 - Choose Colour & Size



mm
Maximum: 2000mm
mm
Maximum: 1000mm

Step 2 - Optional Extras

Read more about Number of Holes

Number of Holes

Please enter how many holes you would like drilling.

If you have ordered standard holes we will drill 5mm holes centred 25mm from the edges in each corner or evenly spaced (depending on how many you order) unless you tell us otherwise.

A drilled hole can be a maximum diameter of 20mm, anything above this size would need to be ordered as a cut-out.

For panels 150mm wide or less the holes will be centred 15mm from the edge of the material unless you tell us otherwise. To avoid compromising the material, holes cannot be centred any closer to the edge than 15mm

If you would like to tell us exactly where you would like your holes drilling and the hole diameter you can do so as you checkout. Please provide your instructions to us in our 'Special Comments’ box which you will see before you pay for your order.

Alternatively, if you have a drawing you can upload it and attach it with your order.

That’s it. If we have any question’s we’ll be in touch. Thanks.

Read more about Hole Types

Holes Type

Please enter the number of holes you would like us to drill.

A drilled hole can be a maximum diameter of 20mm, anything above this size would need to be ordered as a cut-out.

If you would like to tell us exactly where you would like your holes drilling and the hole diameter you can provide your instructions to us in our 'Special Comments’ box which you will see just before you pay for your order.

Alternatively, if you have a drawing you can upload it and attach it with your order.

Otherwise, if you order 4 holes we will drill 5mm holes 25mm from the edges in each corner.  Or, evenly spaced depending on how holes many you order.

That’s it. If we have any question’s we’ll be in touch. Thanks.

Read more about Hole Position Design

Hole Position Design

If you'd like to send us a drawing to show any requirements please upload it here. It will come to us along with your order details once you have paid.

File must be 5MB or less and be a PDF or image with any of the following extensions:

  • .gif
  • .pdf
  • .png
  • .jpg
  • .jpeg
Read more about Screws

Screws

Our screws are 3.5mm x 30mm wall screws

Read more about Screw Covers

Screw Covers

Our screw covers are chrome effect

Read more about Rounded Corners

Rounded Corners

We will round corners with a 25mm radius unless you tell us otherwise.

If you would like to specify the radius you can do so as you checkout. Please provide your instructions to us in our 'Special Comments’ box which you will see before you pay for your order.

£3.00
Get Quote Via Email Read more about 'Add to quote'
Send quote via email

Not ready to order yet? Get an instant quote via email to continue later or to send to your colleague to order.

Sample available

£3.00 each or 2 for £5.00

What Our Customers Say...

5 stars from our customers
Excellent
Based on 1 reviews
See some of the reviews here.

Inspiration

Want To Know More...

Nylon Sheets

A primary engineering material, suitable for virtually any plain bearing application this unmodified grade, Nylon 6 sheets have similar characteristics to Nylon 66 sheets but with significantly lower stress levels combined with high strength, good creep and wear resistance, heat ageing properties and machinability. The Black sheets offer great dimensional accuracy when machining, improved sliding properties, wear resistance, lower surface friction and enhanced UV resistance over natural.

We cut our nylon sheets to the exact size you need.  Simply enter your measurements above. You can inform us of any requests you may have in the Special Comments box at the checkout. If you have other special requirements please see below.

How To Order Your Cut To Size or Shape Nylon

  • We cut our nylon sheets to the exact size you need.  Simply enter your measurements in our Quote Calculator above.
  • We also cut our nylon sheets to shape. Access this service via the Cut To Shape tab which you'll find at the top of our Quote Calculator.
  • If you'd like to send us a drawing of your requirements you can also upload it using our Quote Calculator.  It will arrive with our team once you have placed your order through our checkout.
  • Something else to tell us ?  If you have any other special comments, you can let us know in the Comments box as you checkout.

That's it. If we have any questions, we'll be in touch.

 Alternatively,  email us a drawing of your requirements for a quote. We're happy to help.

If you'd like to speak with our friendly team they can reached on 0113 249 2222.

Key Benefits of Nylon

  • Universally acknowledged as the primary engineering polymer
  • Excellent mechanical, thermal and chemical resistance properties
  • Good PV and load bearing capabilities
  • Improved characteristics over extruded polyamides
  • Excellent wear and abrasion resistance
  • Good dimensional stability, largely free from internal stresses
  • FDA compliance
  • Available in a wide range of colours to order

Typical Uses

  • High mechanical strength, stiffness and hardness
  • Good fatigue resistance
  • High mechanical damping ability
  • Good sliding properties
  • Excellent wear resistance
  • Good electrical insulating properties
  • Good resistance to high energy radiation (gamma- and X-rays-)
  • Good machinability
  • Example Applications
  • Sleeve and slide bearings, wear pads, support and guide wheels, conveyor rollers, tension rollers, sleeves for wheels and rollers, pulleys and pulley-linings, cams, buffer blocks, hammer heads, scrapers, gear wheels, sprockets seal-rings, feed screws, star wheels, cutting and chopping boards, insulators, .

Related Accessories

Sorry, there are currently no Accessories for this product.

Does nylon have good wear resistance?
Nylon 6 and 66 are classed as high wear resistant plastics, as are:
•    Acetal
•    Delrin
•    Oilon
•    HDPE
•    Polypropylene
•    Polyurethane
•    PEEK
•    RG1000
•    Whale Tufnol
•    UHMWPE
•    PET

Does nylon offer high chemical resistance?
Nylon is not considered good for chemical resistance.  The following plastics are:
•    Acetal
•    HDPE
•    Polypropylene
•    PTFE
•    PEEK
•    PVC
•    RG1000
•    UHMWPE

Is nylon considered easy to machine?
Nylon is generally considered as easy to machine  as are:
•    Acetal
•    Delrin
•    Oilon
•    HDPE
•    PEEK
•    PVC
•    RG1000
•    Tufnol
•    UHMWPE

Is nylon easy or difficult to bond?
Nylon is considered easy bond. The following plastics are also considered easy to bond:
•    Nylon 6
•    Nylon 6.6
•    PEEK
•    PVC
•    Polyurethane
•    Tufnol
•    Acrylic
•    Polycarbonate
•    ABS

These plastics are considered difficult to bond:
•    Acetal
•    Delrin
•    Oilon
•    HDPE
•    Polypropylene
•    PTFE
•    RG1000
•    UHMWPE
•    PVDF

What are the differences between Nylon 6 and Nylon 6.6?
Nylon 6.6 has a 6% higher operating temperature, is 13% harder, 10% more rigid and has a tensile strength that is 8% greater. Nylon 6 on the other hand has a greater size range but the main difference is it can be around 30% cheaper

What is the operating temperatures of nylon 6?
100 degrees centigrade long term; 160 degrees centigrade short term. Long term typically means between 5,000 and 20,000 hours operating at this temperature without losing more than 50% of its performance. Short term typically means upto 2 hours at any one time.

To find out more about our delivery service and charges, please click here to visit our delivery information page.

Help & Advice

For more help, advice and examples of innovative use of plastic throughout the home and garden, why not visit our blog.

Data Sheet


Download Data Sheet
