Home /Plastic / Plastic / Acetal / Acetal Natural Extruded

Acetal Natural Extruded

from £3.00

Offer: £9.00 standard delivery. Checkout today!
Acetal Natural Extruded image

Step 1 - Choose Colour & Size
mm
Maximum: 1000mm
mm
Maximum: 2000mm

Step 2 - Optional Extras

Read more about Number of Holes

Number of Holes

Please enter how many holes you would like drilling.

Location - If you order standard holes we will drill 5mm holes centred 25mm from the edges in each corner or evenly spaced (depending on how many you order) unless you tell us otherwise.  For panels 150mm wide or less the holes will be centred 15mm from the edge of the material unless you tell us otherwise. To avoid compromising the material, holes cannot be centred any closer to the edge than 15mm. If you order less than four holes please tell us where you would like them drilled.

Size -  we drill holes to a maximum diameter of 20mm. If you need anything above this size please order it as as 'Cut-Out'.

Giving Us Instructions - you can specify your hole diameter and location as you checkout. Please provide your instructions in our 'Special Comments’ box which you will see before you pay for your order.

Alternatively, if you have a drawing you can upload it and attach it with your order.

That’s it. If we have any question’s we’ll be in touch. Thanks.

Read more about Hole Types

Holes Type

We can drill stndard holes or counter sunk holes.  Please choose from our menu.

If you require advice, please contact our friendly team on 0113 249 2222.

Read more about Cut Outs

Cut Outs


We can cut shapes out of your plastic for you. For example, socket holes in acrylic splashbacks.

Please upload a drawing showing what you would like with sizes marked on.

If you need any assistance, please call our friendly team on 0113 249 2222.

Read more about Hole Position Design

Sending Us A Drawing

If you'd like to send us a drawing to show any requirements please upload it here.

It will come to us along with your order.

​ You can upload a PDF or an image with any of the following extensions:

  • .gif
  • .pdf
  • .png
  • .jpg
  • .jpeg
Read more about Screws

Screws

Our screws are 3.5mm x 30mm wall screws

Read more about Screw Covers

Screw Covers

Our screw covers are chrome effect

Read more about Rounded Corners

Rounded Corners

Please enter how many corners you would like rounded.  If you require less than four corners rounding please tell us which corners they are.

Radius - We will round corners with a 25mm radius unless you tell us otherwise.  If you would like to specify the radius you can do so as you checkout

Giving Us Instructions -  . Please provide your instructions in our 'Special Comments’ box which you will see before you pay for your order.  Alternatively, if you have a drawing you can upload it and attach it with your order.

That’s it. If we have any question’s we’ll be in touch. Thanks.

£3.00
Add to Basket
Get Quote Via Email Read more about 'Add to quote'
Send quote via email

Not ready to order yet? Get an instant quote via email to continue later or to send to your colleague to order.

Sample available

£3.00 each or 2 for £5.00
Watch our Acetal Natural Extruded video

Customer Projects

Manufactured by our Customers

Want To Know More...

Acetal

Acetal offers an ideal combination of strength, toughness and hardness with excellent slide especially suited for chemical applications.

Our Acetal extruded co-polymer sheets are semi crystalline thermoplastic and characterised by a low coefficient of friction, good wear properties and offer resistance to a wide range of chemicals, including many solvents. They also provide high mechanical strength, stiffness and heat resistance. As water absorption is very low, dimensional accuracy and stability is improved over nylons.

Features:

  • High mechanical strength, stiffness and hardness
  • Excellent resilience
  • Good creep resistance
  • High impact strength, even at low temperatures
  • Very good dimensional stability (low water absorption)
  • Good sliding properties and wear resistance
  • Excellent machinability
  • Good electrical insulating and dielectric properties
  • Physiologically inert (most grades are suitable for food contact)

How To Order Your Cut To Size or Shape Natural Acetal

  • We cut our acetal sheets to the exact size you need.  Simply enter your measurements in our Quote Calculator above.
  • We also cut our acetal sheets to shape. Access this service via the Cut To Shape tab which you'll find at the top of our Quote Calculator.
  • If you'd like to send us a drawing of your requirements you can also upload it using our Quote Calculator.  It will arrive with our team once you have placed your order through our checkout.
  • Something else to tell us ?  If you have any other special comments, you can let us know in the Comments box as you checkout.

That's it. If we have any questions, we'll be in touch.

 Alternatively,  email us a drawing of your requirements for a quote. We're happy to help.

If you'd like to speak with our friendly team they can reached on 0113 249 2222.

Related Accessories

Sorry, there are currently no Accessories for this product.

Does acetal have good chemical resistance?
Yes, acetal is considered good for chemical resistance as are:.
•    HDPE
•    Polypropylene
•    PTFE
•    PEEK
•    PVC
•    RG1000
•    UHMWPE

Does acetal have good wear resistance?
Acetal is classed as a high wear resistant plastic as are:
•    Delrin
•    Nylon 6
•    Nylon 6.6
•    Oilon
•    HDPE
•    Polypropylene
•    Polyurethane
•    PEEK
•    RG1000
•    Whale Tufnol
•    UHMWPE
•    PET

Is acetal considered easy or difficult to bond?
Acetal is considered difficult to bond.  These plastics are considered easy to bond:
•    Nylon 6
•    Nylon 6.6
•    PEEK
•    PVC
•    Polyurethane
•    Tufnol
•    Acrylic
•    Polycarbonate
•    ABS

These plastics are considered difficult to bond
•    Acetal
•    Delrin
•    Oilon
•    HDPE
•    Polypropylene
•    PTFE
•    RG1000
•    UHMWPE
•    PVDF

Is acetal easy to machine?
Acetal is considered easy to machine as are :
•    Delrin
•    Cast Nylon 6
•    Nylon 6.6
•    Oilon
•    HDPE
•    PEEK
•    PVC
•    RG1000
•    Tufnol
•    UHMWPE

What is the operating temperatures of acetal ?
100 degrees centigrade long term; 140 degrees centigrade short term. Long term typically means between 5,000 and 20,000 hours operating at this temperature without losing more than 50% of its performance. Short term typically means upto 2 hours at any one time.

To find out more about our delivery service and charges, please click here to visit our delivery information page.

Help & Advice


For more help, advice and examples of innovative use of plastic throughout the home and garden, why not visit our blog.

Data Sheet


Download Data Sheet
